The family of WIFI BOARDS has been designed for easy and wireless testing of RF chips. Each board is built around a specific RF chip and contains an ESP32 microcontroller with built in WiFi. Use your internet browser on any PC or smart device to connect to the board, open the board's webpage with the test software, and start evaluating.

SI5351A WiFi controlled clock generator
3.5 kHz - 210 MHz
Control parameters: frequency, phase, drive level, invert, spread spectrum and logic level.
Frequency resolution: 1 Hz (frequency<=31 MHz), 5 Hz (frequency <= 146 MHz), 10 Hz (frequency>146 MHz)
Display of all intermediate register calculations and register values. The user can use these for their own applications.
3 channels output. Each one can be controlled independently.
Voltage and current monitor.
Power supply from Lipo/Li-ion battery or micro USB connector. On-board battery charger.
For details and specifications please check

Out of stock. Stock expected April 2021.

Free worldwide delivery (tracked)

MAX2871 WiFi controlled frequency synthesizer
22 MHz - 6300 MHz
Control parameters: output frequency, output power, VCO frequency, reference input frequency, PLL parameters, Lock detect and more.
Display of all register values. The user can use these for their own applications.
1 ppm temperature controlled reference clock (TCXO) for high frequency stability.
Separate low noise power supplies for Pll, charge pump, RFout and TCXO to ensure lowest phase noise.
Power supply from Lipo/Li-ion battery or usb connector. On-board battery charger.
For details and specifications please check

Out of stock. Stock expected April 2021.

£37.99
Free worldwide delivery (tracked)
